Permanent capacitor 3uF 450Vac with terminals

€1.92 Tax included

€1.59 tax excl.

Permanent capacitor 3μF/450Vac for electric motors, power capacitor. The external construction of the capacitors is in cylindrical container with PVC sheath and electrical connection through terminals. Mechanical fixing by threaded shaft and M8 nut.

reference: CBBS 3uF 450Vac

Representative image for illustrative purposes, the article supplied corresponds to the specifications indicated.

No queries yet, leave the first!
Privacy
Shipments
Returns

Permanent condenser,made of cylindrical container and coated with PVC, electrical connection by faston terminals of 6.4x0.8mm.

The main application of this type of capacitors is in single-phase motors, being able to be used equally in switching circuits, damping and general applications.
Mechanical fixation by threaded vastago and M8 nut.

specifications:

  • Manufacturer/Supplier: OMU/Mixwill
  • Reference: CBBS 3uF 450Vac
  • Application: Permanent capacitor
  • Type: Polypropylene
  • Capacity: 3uF
  • Maximum rated voltage: 450Vac
  • Frequency: 50/60Hz.
  • Working temperature range: -40º.. +70ºC
  • Nominal tolerance:
    • J: ±5%
    • K:±10%
  • Dissipation factor (20ºC, 50/60Hz): Tg δ ≤ 0.004
  • Insulation resistance: >2000MΩxμF (20ºC, 500Vdc)
  • Test voltage: 1.75A 2s; 2000Vac 10s
  • Electrical endurance:
    • 400Vac: 10000h
    • 450Vac: 3000h
    • 500Vac: 1000h
  • Type of connection: Terminals of 6,4x0,8mm
  • Dimensions: Ø30x57mm
  • Security protection class: P0/P2
  • Fastening: Threaded vastago and M8x1,25mm nut
  • Regulations: EN60252





Material for professional use, install respecting the regulations in force at the place of installation. Before its installation or handling, it is possible to make sure that the electrical voltage is disconnected and that the capacitor is discharged.
