Relay 24Vac 4 contacts 7A without indication SERIES 55 - FINDER

Name: Relay 24Vac 4 contacts 7A without indication SERIES 55 - FINDER
Brand: FINDER
SKU: 55.34.8.024.00
Price: 7.4415 EUR
Availability: InStock

€7.44 Tax included

€6.15 tax excl.

Relay of 4 contacts 24Vac and 7A. 4 changeover contacts (4PDT). For general purpose and industrial applications, capable of handling medium loads.

Flat pin for connection on base or direct soldering.

Part number: 55.34.8.024.0000

Representative image for illustrative purposes, the item supplied will correspond to the specifications indicated.

No queries yet, leave the first!

Privacy

Shipments

Returns

Relay with 4 contacts 24Vac, 4 contacts switched type of 7A and pins to be inserted on 94 series socket of FINDER.

Designed for general use and for other specific applications such as control panels, control and distribution panels, automation, management and control of electrical networks, road and tunnel lighting, switches, etc.

Characteristics:

Manufacturer: FINDER
Part no: 55.34.8.024.0000
SERIES 55
Contact configuration: 4PDT
94 series sockets for PCB, soldering or 35 mm bar mounting (EN 60715) with push-in, quick-connect or cage clamp terminals
Contacts cadmium-free

Technical data:

Contact configuration: 4 switched
Nominal coil voltage: 24Vac
Coil current: 53mA
AC contact rating (with resistive load): 7A / 250Vac
DC contact rating (resistive loaded): 7A / 30Vdc
Maximum contact current: 15A
Switched voltage: max. 220 VDC, max. 250 VAC
Coil resistance: 190Ω, ω
Body dimensions: 27,7x20,7x35,8 mm
Power consumption of coil: 1.5VA
Standard contact material: AgNi
Dielectric strength between open contacts: 1000VAC
Ambient temperature: -40 to ^+85o C
Conductors: Connectors made of 2.8x0.5mm

Material for professional use, must be installed by qualified personnel in compliance with the regulations in force at the place of installation.

Finder Serie 55

Download (4.09MB)
