Solenoid valve 3/8 3-way bistable assisted - Metal Work

€94.40 Tax included

€78.02 tax excl.

Pneumatic solenoid valve of 3/8" 3 bistable assisted tracks, for industrial applications and general use. Supports coils of size 22mm with core of Ø8mm.

Reference: 7040020300

esquema neumatico electrovalvula 3 vias biestables asistidas

Logo-Metal-Work


Representative image for illustrative purposes, the item supplied will correspond to the specifications indicated.


No queries yet, leave the first!
Privacy
Shipments
Returns


Pneumatic solenoid valve of 3/8 3 ways 2 positions assisted bistable. For general and industrial applications. The coil is not included in the supply.


Characteristics:

  • Provider: Metal Work
  • Reference: 7040020300- SOV C3 SEB OO
  • Operating pressure: 2.5 ÷10 bar
  • Minimum assist pressure: 2.5 bar
  • Operating temperature: -10 ÷ +60
  • Nominal diameter: 13.3 mm
  • Conductance C Nl/min · bar: 505.52
  • B bar/bar critical ratio: 0.32
  • Flow rate at 6 bar ΔP 0.5 bar Nl/min: 1560
  • Flow rate at 6 bar ΔP 1 bar Nl/min:2150
  • Monostable TRA/TRR at 6 bar ms: 21/72
  • Bistable TRA/TRR at 6 bar ms: 18/18
  • Voltage according to coils: 12; 24 VDC - 24; 110; 220V AC 50/60Hz
  • Voltage tolerances %: -10 ÷ +15



Material for professional use, install in compliance with the regulations in force at the place of installation.

To expand the information you can download the technical sheet by clicking on the "Attachments" tab
