3150VA ultra-isolation IP-20 transformer
3150VA ultra-isolation IP-20 transformer

Transformer 3150VA 230/230Vac ultra-insulated IP-20

Special manufacturing material
€374.47 Tax included

€309.48 tax excl.

single-phase transformer of 3150VA primary 230Vac secondary 230Vac,intended for the supply of circuits where galvanic separation of tracking and filtering of disturbances is required.

Manufactured in resin encapsulator, protection degree IP-20.

Part number: TRIA3150-230-230

esquema transformador monofásico con pantalla 230-230

No queries yet, leave the first!
Privacy
Shipments
Returns


3150VA single-phase ultra-isolated transformer,for control and maneuver in electrical circuits where safety galvanic isolation and disturbance filtering are required. They are manufactured in several primary and secondary voltages.

Ultra-isolated transformer with pharadic kick. Separation of the primary and secondary circuits from a safety electrostatic screen that filters and grounds unwanted signals and disturbances. The degree of leakage depends directly on the quality of the grounding of the installation.

Manufactured with resin encapsulation providing an IP-20 degree of protection.

Technical characteristics of the transformer:

  • Part No.: TRIA3150-230-230
  • Available primary/secondary voltages: 230/230Vac
  • Transformer power: 3150 VA.
  • Windings: Thermal class N 200oC.
  • Insulators: Thermal class B 130oC.
  • Frequency: 50/60 Hz.
  • Protection: IP-20.
  • Transformer test voltage
    • 5 KV between windings.
    • 2.5 KV between windings and ground.
  • Ambient temperature: Tao 25oC.
  • Transformer encapsulation: Self-extinguishing resin.
  • Transformer mounting: by means of screws.
  • Certificate: UNE-EN61558

Indicaciones de medicas transformadores monofasicos en resina

Table dimensiones transformadores monofasicos TRIA

Esquema electrico transformador separador con triple pantalla
