8000VA 230/400Vac IP-00 single-phase autotransformer
8000VA 230/400Vac IP-00 single-phase autotransformer

Single-phase autotransformer 8000VA 230/400Vac IP-00

Special manufacturing material
€353.17 Tax included

€291.88 tax excl.

autotransformer reversible single-phase of 8000VA, allows the adaptation of voltage between 230 and 400Vac.

It allows to adapt the tension in small machinery and cabinets for automatisms in an economical way.

Reference: AT2-8000

Esquema eléctrico de autotransformador monofásico

No queries yet, leave the first!
Privacy
Shipments
Returns


autotransformer single-phase for voltage change, reversible, intended for voltage change. They are indicated when it is necessary to adapt the voltage from 230 to 400v / 400 to 230Vac, in an economical way, without galvanic separation. Its usual field of application is used in small machinery and automatisms.

Manufactured with low loss magnetic sheet and copper wire windings, providing high performance.

Specifications:

  • Ref: AT2-8000
  • Transformation ratio: 230/400Vac
  • Power: 8000VA.
  • Frequency: 50/60Hz.
  • Windings: Thermal class N 200ºC.
  • Test voltage: 3KV between mass.
  • Insulators: Thermal class F 155ºC AND H 180ºC.
  • Protection: IP-00.
  • Ambient temperature: TA=25ºC.
  • Cooling: ANAN ( natural Air).
  • Certificate: UNE-EN 61558.
