Single-phase autotransformer 10000VA 230/400Vac IP-00
Single-phase autotransformer 10000VA 230/400Vac IP-00

Single-phase autotransformer 10000VA 230/400Vac IP-00

Special manufacturing material
€397.82 Tax included

€328.78 tax excl.

Single-phase reversible autotransformer of 10000VA, allows voltage adaptation between 230 and 400Vac.

It allows to adapt the voltage in small machinery and cabinets for automatisms in an economical way.

Reference: AT2-10000

Esquema eléctrico de autotransformador monofásico
Representative image for illustrative purposes, the item supplied will correspond to the specifications indicated.

1 question about the product
Privacy
Shipments
Returns


Single-phase autotransformer for voltage change, reversible, intended for voltage change. They are indicated when it is required to adapt the voltage from 230 to 400v / 400 to 230Vac, in an economic way, without galvanic separation. Their usual field of application is the use in small machinery and automatism.

Manufactured with low-loss magnetic sheet and with wire windings of copper, providing high performance.

Technical characteristics:

  • Reference: AT2 10000
  • Transformer ratio: 230/400Vac
  • Power: 10000VA.
  • Frequency: 50/60Hz.
  • Windings: Thermal class N 200ºC.
  • Test voltage: 3KV between ground.
  • Insulation: Thermal class F 155ºC and H 180ºC.
  • Protection: IP-00.
  • Ambient temperature: TA=25ºC.
  • Cooling: ANAN (Natural air).
  • Certificate: UNE-EN 61558

The autotransformer is supplied without any type of overload protection, it is mandatory to install them to avoid overloading the transformer. The power and current indicated are apparent, the active current provided by the transformer will depend on the power factor of the connected load.
Material for professional use, install in compliance with the regulations in force at the place of installation.

Questions

Question
What is the dimensions of below product ? Specifications: Ref: AT2-10000 Transformation ratio: 230/400Vac Power: 10000VA. Frequency: 50/60Hz. Windings: Thermal class N 200ºC. Test voltage: 3KV between mass. Insulators: Thermal class F 155ºC AND H 180ºC. Protection: IP-00. Ambient temperature: TA=25ºC. Cooling: ANAN ( natural Air). Certificate: UNE-EN 61558
Answer
Goof afterrnon,

Dimensions for AT2-10000 are Height 225mm ,  Width 195mm, Depth 195mm. Weight 35Kg.

Best regards
Saud on 02/11/2023 22:41:17
