SPZ 140x2 V-belt pulley T1610 taper slots

€46.44 Tax included

€38.38 tax excl.

Pulley for trapezoidal belts Ø140mm, two slots. Machined for conical bushing - taper lock T1610. Made of cast steel and valid for all belts with "V" profile type Z and SPZ. Manufactured according to ISO4183 - DIN2211.

  • Type of straps: Profile in "V" type Z and SPZ.
  • Diameter. 140mm.
  • number of strap slots: 2.
  • Taper: T1610.

Imagen representativa para fines ilustrativos, el artículo suministrado corresponderá a las especificaciones indicadas.

1 question about the product
Privacy
Shipments
Returns


Pulley for trapezoidal belts profile in "V", for mechanical transmission. Made of cast iron and steel, and according to DIN2211 - ISO4183.

Machined trapezoid pulley for conical bushing "Taper Lock".

Specifications:

  • Type: trapezoid profile in "V".
  • Models: Z and SPZ.
  • Material: cast steel.
  • Primitive diameter: 140mm.
  • Number of slots: 2.
  • Type of conical bushing - taper: T1610
  • Manufacturing standard: DIN2211 - ISO4183.


Note: The taper (conical bushing) is not included in the supply.

Dimensions:

  • (Dp): 140
  • (Od): 146
  • (F): 28
  • (J): 115
  • (K): 3
  • (L): 25
  • Taper: 1610



Material for professional use, install in compliance with the regulations in force at the place of installation.

Questions

Question
Shaft dia ?
Answer
Dear Customer,

These pulleys are to fit a size 1610 taper.
Then, when purchasing the taper for this pulley, you have to select the shaft size.

All the best
ADAJUSA
Abdul Qadeer khan on 06/20/2024 14:01:56
