Miniature circuit breaker LS 9A coil 230Vac auxiliary contact closed NC

Miniature circuit breaker 9A coil 400Vac auxiliary contact closed NC - LS

Name: Miniature circuit breaker 9A coil 400Vac auxiliary contact closed NC - LS
Brand: LS Electric
SKU: 97GMC9MA40B
Price: 16.3108 EUR
Availability: InStock

€16.31 Tax included

€13.48 tax excl.

Three-phase electricmini contactor for motor control, heating, lighting, ventilation, or general uses, 3-pole with a current capacity of 9A category AC3 or 20A category AC1, with 380-400Vac coil, the contactor is equipped with a closed auxiliary contact (NC).

Part number: GMC-9M-01-AC400V

Esquema eléctrico contactor 3P auxiliar NA

Logotipo LS LG industrial Systems

No queries yet, leave the first!

Privacy

Shipments

Returns

Three-phase(3-pole)miniature contactor of 9A in category AC3 or 20A in category AC1, the contactor coil voltage is 380-400 Vac, with a closed auxiliary NC contact. The contactor can be fixed by screws or DIN rail. Mainly designed for control of electric motors, heating, lighting, ventilation, and general uses.

General characteristics of the mini contactor:

Manufacturer: LS.
Reference: GMC-9M-01-AC400V
number of poles: 3.
Rated current AC3: 9A.
Maximum thermal current Ith: 20A.
Maximum voltage: 660Vac.
Maximum power: 3~AC3 230V: 2.2 Kw.
Maximum power: 3~AC3 400V: 4 Kw.
Control voltage (coil): 220-230Vac 50/60Hz.
Auxiliary contact integrated in the mini contactor: 1 closed contact (NC).

Dimensiones contactor LS Electric vista frontal

Minicontactor LS Electric Vista lateral y posterior

Mini-contactors catalog

Download (464.28KB)

Questions

Be the first to ask a question about this product!

Question about the product

Name ^*

Email ^*

Question ^*

^* Required fields

I have read and agree to the conditions of use (read)
