Voltmeter 0-250Vdc 96x96

Name: Voltmeter 0-250Vdc 96x96
Brand: TRACON
SKU: DCVM96-250
Price: 18.997 EUR
Availability: PreOrder

€19.00 Tax included

€15.70 tax excl.

Analog voltmeter with measurement range 0-250 V in direct voltage. 96x96mm transpanel mounting. It allows you to view the value of a voltage very quickly and visually.

Reference: DCVM96-250

Representative image for illustrative purposes, the item supplied will correspond to the indicated specifications.

No queries yet, leave the first!

Privacy

Shipments

Returns

Description
Frequently questions

Analog voltmeter for direct measurement of continuous voltage in a measurement range of 0 to 250 V, panel with logarithmic scale. The voltmeter is prepared for transpanel mounting measuring 96x96mm.

Manufactured in ABS box, easy and simple installation. They have a long-term and momentary overload factor.

It has zero adjustment through a regulator located on the front of the measuring instrument. The measurement scale is engraved in black on an aluminum plate painted in white.

Characteristics:

Manufacturer/Supplier: Tracon
Reference: DCVM96-250
Type of measurement: Direct current voltage
Measurement range: 0-250V
Connection type: Direct
Class (accuracy): 1.5
Frame dimensions: 96 x 96mm
Cutting size: 90mm
Working temperature: -25ºC...+55ºC
Protection degree (from the front side): IP52
Terminal protection degree: IP00
Terminal protection degree (cover): IP20
Regulations: EN60051, IEN 61010

Connection:

DCVM96DIAGRAM

Dimensions:

DCVM96DIMENSIONS

Material for professional use, install in compliance with the regulations in force at the installation site.
