Manual lever valve 1/4 3/2 monostable lever 90 degrees - Metal Work

€74.77 Tax included

61.79 tax excl.

7020000100

Valve of 1/4 manual lever drive. 3 ways 2 positions return spring, metal body, lever of action to 90º. For control of cylinders of simple effect.

Reference: 7020000100

Logotipo Metal Work

Representative image for illustrative purposes, the item supplied will correspond to the specifications indicated.

No queries yet, leave the first!

Valve of 1/4 manual actuation by lever of 2 positions return spring, 3 ways 2 positions that allow to control cylinders of simple effect. In one position the cylinder is collected, in another position the cylinder advances. it can also be used as a passage valve or pneumatic circuit cut-off.

Angle lever drive at 90º.

Manufacturer: Metal Work.
Reference: MAV 33 LES NC Code: 7020000100
Operating pressure Bar: Empty ÷ 10
Operating temperature °C: -10 ÷ +60
Nominal diameter mm: 7.55
Conductance C Nl/min · bar: 264.26
Critical ratio b bar/bar: 0.27
Flow rate at 6 bar ΔP 0.5 bar Nl/min: 750
Flow rate at 6 bar ΔP 1 bar Nl/min: 1100

Material for professional use, install in compliance with the regulations in force at the place of installation.

To expand the information you can download the technical sheet by clicking on the "Attachments" tab

70 manual series valves

Download (1.51MB)
