Endless crown reducer size. 30 63B14
Endless crown reducer size. 30 63B14

Endless crown reducer Size 30 Flange PAM 90/11 - Motor housing 63 B14

€65.39 Tax included

€54.04 tax excl.

With hollow output shaft of Ø14mm, and input flange PAM 90/11 (Ø Ext 90mm and Ø Input shaft 11mm) type B14, suitable for motors with housing size 63.

Available reduction ratios: 7,5-10-15-20-25-30-40.

The usual motor powers for these reducers are 0.16hp and 0.25hp (maximum recommended ratio I=25) 1500 rpm.

Reduction ratio
  • 7.5
  • 10
  • 15
  • 20
  • 25
  • 30
  • 40

No queries yet, leave the first!


Endless reducer crown of size 30, compact execution and high performance, with hollow output shaft of Ø14mm and input shaft of Ø11mm.

This reducer size supports B14 flange motors size 63, this flange size has an Outer Ø of 90mm and the reducer has an inlet shaft diameter of 11mm, PAM 90/11.

Dimensiones brida entrada reductor sinfin corona

  • P: 90mm.
  • M: 75mm.
  • N: 60mm.
  • D: Ø11mm.

Usual motors for these reducers are 0.16hp and 0.25hp (maximum recommended ratio I=25) 1500 rpm.

The reduction ratios (i) available are from 7.5 to 40, depending on the input revolutions we can obtain the following revolutions on the output axis shown in the following table.

Tabla de revoluciones de salida reductores

Dimensiones reductor sinfin corona tamaño 30

You can download all the dimensions of the reducer by clicking on the "ATTACHMENTS" tab.
