Tensioning pinions for roller chain ISO DIN 606
Tensioning pinions for roller chain ISO DIN 606

Tensioning sprockets for roller chain Z13 3/4 x 7/16 12B DIN 8187 ISO 606

€20.76 Tax included

€17.16 tax excl.

Tensioning pinions for roller chain 3/4" x 7/16" according to European standard DIN 8187 ISO 606

Reference: PINHON TENSOR Z13 3/4 C/ROD.8

Teeth: 13

Step: 3/4"x7/16"

ISO: 12B-1

Representative image for illustrative purposes, the item supplied will correspond to the specifications indicated.

No queries yet, leave the first!

13-tooth tensioning pinion for roller chain 3/4" x 7/16" according to European standard DIN 8187 ISO 606

Manufacturer: Technox
Reference: PINHON TENSOR Z13 3/4 C/ROD.8

The wheels or tensioning sprockets for chains are units of guidance and forwarding of chains, being valid for normal chains and rollers. They serve to compensate for the elongations of the chains, which occur throughout the service life by the operation itself, improve the smoothness of the ride and increase the performance of the system under high loads and speeds.

The units are supplied ready for assembly, are composed of wheel for the chain and rigid ball bearing already assembled. The tensioning wheels for chains are made of high-strength sintered steel. As the inner ring of the rigid ball bearing is extended on both sides, no additional separator rings are required.

The inner ring is fixed to the shaft by an eccentric tensioning ring. The drill in this series has a positive tolerance. In this way, unhanhanized shafts up to ISO h9 tolerance can be used under medium loads and speeds.


Withstand low loads and high speeds, and temperatures between -20º C to + 120º C




Characteristics:

  • 3/4" x 7/16" mm - 12B-1
  • Teeth: 13
  • Outer Diameter (Sd): 87.5
  • Primitive diameter (Dp): 79.59
  • Tooth width (A): 11.1
  • Hub diameter (D): 16
  • High bearing (F): 40
  • Bearing width (H): 18.3
  • Wheel width (J): 12
  • Weight: 0.34 Kg


Material for professional use, install in compliance with the regulations in force at the place of installation.
