Compact protector single-phase transient surges TYPE 2 and permanent + IGA 2x32A 10kA COMBI-MINI-2P32T15 - Toscano

€95.90 Tax included

€79.26 tax excl.

Type 2 and permanent transient surge protector with built-in IGA 2x32A pre-wired for single-phase installations, compact size that reduces the installation space by including in the same permanent trigger coil the transient protection, thus adapting to small spaces.

Surge protection module provides protection against permanent surges due to increases in mains voltage and against transient surges (lightning strikes or network switches). breaking capacity of IGA 10kA, maximum discharge intensity 15kA. Plug-in cartridge for easy replacement.

Reference: COMBI-MINI-2P32T15



Toscano_version 1 color sin leyenda
Representative image for illustrative purposes, the item supplied will correspond to the specifications indicated.

No queries yet, leave the first!


Combined protection assembly against transient (ground discharger) and permanent surges, associated with a 2-pole cutting device (IGA) with a breaking capacity of 10kA according to IEC-EN 63052, curve "C".

The equipment measures the voltage in the installation permanently and detects any increase in it, greater than 10% of the nominal voltage. In case of detecting this anomaly, it acts on the IGA (Automatic General Switch), disconnecting the voltage in the installation. The time of action will depend on the level of overvoltage detected (according to specifications of the UNE-EN 50550 Standard).

The device will be operational again once it is manually rearmed, as long as the voltage is between its nominal values.

In the event that a transient overvoltage occurs, the equipment absorbs it, deriving it to the ground thus preventing it from causing any damage to the devices connected to the network. The warning window will be continuously illuminated in green.

If due to a transient surge the protection becomes inoperative, it will show the warning window in red. In this case, the protective module will have become unusable, and must be replaced by another.

The whole assembly is supplied fully assembled and pre-wired.

General characteristics:

  • Manufacturer/: Toscano
  • Reference: COMBI-MINI-2P32T15
  • Rated voltage: 240 VAC
  • Frequency: 50-60 Hz
  • Maximum terminal section: 25mm2
  • Mounting: Rail DIN 35
  • Number of DIN modules: 3
  • Standards: UNE-EN 60898 , UNE-EN 50550 , IEC 61643-11 , EN 61643-11


Permanent Features:

  • Trigger voltage: >265VAC ± 2%
  • Overvoltage response time: according to UNE-EN 50550


Transient Features:

  • Maximum Imax intensity : 12,5 kA ; 8/20
  • Rated current In: 6 kA
  • Protection level Up: ≤1.5kV
  • Type: 2


IGA Features:

  • Rated current: 32 A
  • Curve: C
  • breaking capacity: 10 kA


For the proper functioning of the equipment, the phase must be connected to the terminal block "L" and the neutral in the terminal block "N"




Note: The ability to protect against transient surges depends largely on the quality of the grounding.

To expand the information you can download the technical sheet by clicking on the "Attachments" tab.
Material for professional use, install in compliance with the regulations in force at the place of installation.
