Miniature relay 230Vac 1 contact 12A SERIES 40 - FINDER

Name: Miniature relay 230Vac 1 contact 12A SERIES 40 - FINDER
Brand: FINDER
SKU: 40.51.8.230
Price: 6.171 EUR
Availability: InStock

€6.17 Tax included

€5.10 tax excl.

Mini relay type 40.51 for printed circuit and plug-in sockets, 230Vac and 1 12A changeover contact.

Reference: 40.51.8.230.0000

Representative image for illustrative purposes, the item supplied will correspond to the specifications indicated.

No queries yet, leave the first!

Privacy

Shipments

Returns

230Vac Miniature relay , with 1 12A switched contact and pins so that they can be soldered directly onto a printed circuit board (PCB) or inserted into a socket.

Mounting on printed circuit board or 95 series sockets.

Designed for general uses and for other specific applications such as control panels, command and distribution panels, automation, toys, electronic cards, electromedicine, etc.

Characteristics:

Manufacturer: FINDER
Reference: 40.51.8.230.0000
SERIES 40
Contact Configuration: DPDT
Contact separation 5 mm
Variant with cadmium-free contacts
8 mm Isolation , 6 kV (1.2 / 50µs) between coil and contacts
Compliance with glow wire test according to EN 60335-1
95 series sockets for printed circuit board, or for mounting on 35 mm rail (EN 60715) with push-in, quick-connect or cage terminals

Technical characteristics:

Contact configuration: 1 switched
Nominal supply voltage: 230Vac
Nominal contact voltage: 250Vac
Contact rated current: 12A
Nominal load in AC1: 3000VA
Rated load at AC15 (230 V AC): 1000VA
Single-phase motor (230 V AC): 0.5kW
Coil/contacts Isolation : 6kA
Standard contact material: AgNi
Mechanical life: 10x10 ⁶ cycles
Electrical life with nominal load in AC1: 200x10 ³ cycles
Dielectric strength between open contacts: 1000Vac
Ambient temperature: -40 to +80 ^o C
Dimensions: 12.4 x 25 x 29 mm

Connection diagram:

Dimensions (mm):

Professional use material, it must be installed by qualified personnel in compliance with the regulations in force at the place of installation.
