Collector 5 inlets 6 and 4 with 55000 Series fittings - 5 inlets 6 and 4 with 55000 Series fittings - Aignep

Name: Collector 5 inlets 6 and 4 with 55000 Series fittings - 5 inlets 6 and 4 with 55000 Series fittings - Aignep
Brand: Aignep
SKU: 5535064
Price: 5.082 EUR
Availability: InStock

€5.08 Tax included

€4.20 tax excl.

Manifold manifold with 2 fittings diameter 6mm and 3 fittings diameter 4mm, made of technopolymer.Veryefficientconnection simple that allows reconnection thousands of times without compromising the perfect pneumatic and mechanical retention.

Series: 55000
Reference: 55350 6-4

Representative image for illustrative purposes, the item supplied will correspond to the specifications indicated.

No queries yet, leave the first!

Privacy

Shipments

Returns

Manifold distributor with 2 fittings with a diameter of 6mm and 3 fittings with a diameter of 4mm, made of technopolymer. Very simple and effective connection that allows reconnection thousands of times without compromising perfect pneumatic and mechanical retention . It has a clamping spring, which clamps the tube without engraving or deforming it, thus allowing greater simplicity in the operation of connecting or disconnecting the tube fitting.

This fitting is suitable for robotics, automotive, textile industry, packaging, handling, compressed air circuits, industrial water and vacuum

Technical characteristics:

Manufacturer: Aignep .
Reference: 55350 6-4
Outer diameters of the tube (two outlets): 6mm
Outer diameters of the tube (three outlets): 4mm
Fluid: vacuum, compressed air and water
Material: Technopolymer
Tube extractor ring: acetal resin
retention gasket: NBR
Clamping spring: stainless steel
Pressure: -0.99 bar at 20 bar
Working temperature: -20ºC to +80ºC
Thread regulations:
- Conical gas conforming to ISO 7.1, BS 21, DIN 2999
- Cylindrical gas according to ISO 228 Class A
- ISO R/262 compliant metric

55350dimensions
55350td

Material for professional use, install in compliance with the regulations in force at the installation site.
