Circuit breaker 4 poles 63A 10kA (4x63A) - LS

€111.22 Tax included

€91.92 tax excl.

4-pole 63A curve C circuit breaker, for protection against short circuits and overloads in single-phase or two-phase installations, of the LS brand. With a rated breaking capacity capacity of 10000A (10kA) and active pole protection with individual status indication for each pole.

Reference: BKH 4P C63A

2-pole circuit breaker electrical diagram

LS logo

Representative image for illustrative purposes, the supplied article will correspond to the indicated specifications.

No queries yet, leave the first!


Circuit breaker 4 poles 63A 10kA curve C, for protection against short circuits and overloads in single-phase or two-phase installations. With a rated breaking capacity capacity of 10000A (10kA) and active pole protection with individual status indication for each pole.

Width per module of 27mm, with a connection section of up to 50mm².



Main characteristics of the magnetothermic :

  • Manufacturer/Supplier: LS (LG)
  • Manufacturer reference: BKH 4P C63A
  • Nominal intensity of the magnetothermic (In): 63A
  • Number of poles: 4 (4x63A)
  • Pitch: 4 modules (108mm)
  • Breaking capacity (Icn): 10000A (10kA)
  • Operating voltage: 230/400Vac, 50/60Hz
  • Characteristic curve: C
  • Endurance: ≥4000
  • Regulations: CE; IEC60947-2
  • Terminal Type: Screw Clamp
  • Capacity for 50mm² cable

OB8-100 circuit breaker dimensions

Material for professional use, install in compliance with the regulations in force at the place of installation.
