MCB circuit breaker 2 poles 50A (2x50A) - Hyundai Electric
MCB circuit breaker 2 poles 50A (2x50A) - Hyundai Electric

MCB circuit breaker 2 poles 50A (2x50A) - Hyundai Electric

€14.41 Tax included

€11.91 tax excl.

2-pole 50A C-curve MCB circuit breaker for protection against short circuits and overloads in single-phase or two-phase installations. With an assigned breaking capacity of 6000A. Active protection of both poles with individual status indication.

Protects both conductors. Can be used in installations and assemblies up to 500V AC.

Reference: HGD63-M2P050C

2 pole magnetic-thermal wiring diagram



Representative image for illustrative purposes, the item supplied will correspond to the specifications indicated.

No queries yet, leave the first!
Privacy
Shipments
Returns


2-pole 50A 6kA "C" curve MCB circuit breaker , for protection against short-circuits and overloads in single-phase or two-phase installations. With an assigned breaking capacity of 6kA, active protection of the poles with status indication. Made of fireproof thermoplastic material. Manufactured according to reference standard IEC/EN60898-1.

Ideal for use in domestic or industrial installations as well as in cabinets for machinery automation. High reliability and performance allowing a high number of work cycles. Protects both conductors.

The main features of this range of products include:

  • Compact design and structure.
  • 13 plates in the extinguishing chamber for effective arc cooling.
  • Trip-free mechanism. The circuit breaker trips even if forced to stay in the ON position.
  • Visual status indication.
  • Supports the mounting of a large number of accessories.



Technical characteristics:

  • Manufacturer/Supplier: Hyundai Electric .
  • Manufacturer reference: HGD63-M2P050C .
  • Nominal intensity of the magnetothermic (In): 50A.
  • Number of poles: 2 (2x50A).
  • Step: 2 modules.
  • Breaking capacity (Icn): 6000A (6kA) (Ics=100% icn).
  • Maximum operating voltage (Ue): 240/415Vac, 50/60Hz.
  • Characteristic curve: C.
  • Rated insulation voltage (Ui): 500Vac.
  • Rated impulse withstand voltage (Uimp): 4 KV
  • Dielectric strength: 2.5kV.
  • Protection: IP20.
  • Endurance: ≥10000/20000.
  • Operating temperature: -5ºC...+55ºC.
  • Humidity: 95% RH.
  • Energy limitation class: Class 3.
  • Terminal Type: Screw Clamping Clamp.
  • Maximum terminal capacity: 25mm².
  • Maximum tightening torque: 2 Nm.
  • Weight: 0.100 Kg.
  • Dimensions (mm): 80.5x71x35.4 mm
  • Mounting position: Vertical/Horizontal.
  • Housing material : Flame retardant molded thermoplastic.
  • Supports mounting of auxiliary elements: YES.
  • Regulations: CE; IEC/EN 60898-1.

HCG63N magnetothermic dimensions


For further information you can download the technical sheet by clicking on the "Attached Files" tab.

Professional use material, install in compliance with the regulations in force at the place of installation.
