2-pole 6A 6kA curve "D" MCB circuit breaker , for protection against short circuits and overloads in single-phase or two-phase installations with the presence of motors or machinery with high initial current, preventing it from tripping during startup. Active pole protection with status indication. Made of fireproof thermoplastic material according to the reference standard IEC/EN 60898-1; 60947-2.
High reliability and performance, allowing a high number of work cycles.
Main characteristics of this range of products:
- Compact design and structure.
- Free firing mechanism. The switch trips even if it is forced to hold in the ON position.
- Visual status indication.
- Supports mounting of accessories.
Technical characteristics:
- Manufacturer/Supplier: Hyundai Electric
- Manufacturer reference: HGD63-M2P006D
- Rated current(In): 6A
- Number of poles: 2
- Characteristic curve: D
- Max operating voltage (Ue): 240Vac, 50/60Hz
- Breaking capacity (Icn): 6kA (Ics=100% Icn)
- Rated insulation voltage (Ui): 500Vac
- Rated impulse withstand voltage (Uimp): 4kV
- Dielectric strength: 2.5kV
- Electrical / Mechanical endurance: 10,000 / 20,000 maneuvers
- Operating temperature: -40C...+55C
- Humidity: 95% RH
- Power limitation class: Class 3
- Terminal type: Screw clamp
- Terminal size: 25mm²
- Maximum tightening torque: 2 Nm
- Protection grade: IP20
- Weight: 0.23kg
- Mounting Position: Vertical/Horizontal
- Housing material : Flame Retardant Molded Thermoplastic
- Supports the assembly of auxiliary elements: Yes
- Regulations: CE; IEC/EN 60898-1; 60947-2
Material for professional use, install in compliance with the regulations in force at the installation site.
