Disconnector switch 4-pole 25A SE series 48x48mm red lever - Giovenzana

Disconnector switch 4-pole 25A SE series 48x48mm red lever - Giovenzana

€18.97 Tax included

€15.68 tax excl.

4-pole disconnector switch (four-poles) 25a. ,rotary knob 90º 0-1. yellow and red lever, made to the strictest European standards, which allow, to meet safety requirements.
Suitable for interruption, connection and switching of electrical circuits as well as direct start of motors and main switch in machines. Suitable up to 11kw. 400Vac.

Reference: GISE160348R
esquema electrico interruptor 4 polos
Giovenzana
Representative image for illustrative purposes, the article supplied shall correspond to the specifications indicated.



4-pole disconnector switch (four-poles) 25a for inductive loads (Electric motors) and general control. Rotary control 90º with two positions 0-1, faceplate in yellow and lever in red.

This series of rotary switches have been made according to the strictest European and international standards (IEC/EN 60947-3, UL508), which allows them to meet all safety requirements.

Mounting by rear-panel fixation (back frame), IP-20 protection grade in terminals, self-cleaning contacts and indelible laser marking. Body made of self-extinguishing material UL94 VO.

This three-phase switch is suitable for machinery, motors and installations up to 7.5kw connected to 230Vac or 11kw connected to 400Vac.

The supply includes:

  • 4-pole switch: SE163004R
  • Faceplate: 002/0001

characteristics:

  • Brand: Giovenzana
  • Switch reference: SE163004R
  • Faceplate reference: 002/0001
  • number of poles: 4.
  • Rated voltage Ue: 690V.
  • Nominal thermal intensity ith: 32A.
  • Nominal intensity Ie (AC21A): 16a.
  • Nominal intensity Ie (AC22A): 25a.
  • Nominal intensity Ie (AC23A):25a.
  • Nominal intensity Ie (AC3):25a.
  • Nominal interrupt capacity: 10kA.
  • Contacts: Slow opening of double interrupt.
  • Number of maneuvers / hours: 120.
  • Mechanical durability: 100,000 maneuvers.
  • Maneuver angle: 90º.
  • Built-in assembly.
  • Degree of protection:
    • Controls type 1-4-4X: IP-65.
    • Bornes: IP-20.
  • Standards: EC; IEC60947; IEC60204; UL508 CSA 22.2 No. 14

Table of intensities and powers of employment:

  • Use category AC-21A: 32A.
  • Use category AC-22A: 25a.
  • Use category AC-23A:
    • Standard three-phase motors 230Vac: 25a - 7,5kW.
    • Standard three-phase motors 400Vac: 25a - 11kW.
  • Use category AC-3:
    • Standard three-phase motors 230Vac: 22A - 7,5kW.
    • Standard three-phase motors 400VAc: 22A - 11kW.

    dimensions:

    Dimensiones interruptor SE1632

    assembly:

    Monaje interruptores serie SE

    As additional elements we can add the following references:

    • Closed auxiliary contact: GIPL004001
    • Open auxiliary contact: GIPL004002
    • Auxiliary contact fastening plate: GI1184021


    Material for professional use, has to be installed respecting the regulations in force at the place of installation.
