Compact pneumatic cylinder 25x60mm double acting ISO 21287 - Metal Work
Compact pneumatic cylinder 25x60mm double acting ISO 21287 - Metal Work

Compact pneumatic cylinder 25x60mm double acting ISO 21287 - Metal Work

€62.51 Tax included

€51.66 tax excl.

Compact pneumatic cylinder Ø25 stroke 60mm, double magnetic effect, rod with female or male thread. Manufactured according to ISO 21287. Extruded aluminium body with slots for magnetic detectors, rod and nut in stainless steel.

In this range of ISO compact cylinders, the heads have been eliminated to facilitate installation, improve robustness,

Available in the following executions:

  • Body in aluminum, stem and nut in stainless steel, female thread
  • Aluminum body, stainless steel stem and nut, male thread


Symbol pneumatic cylinder adajusa
Logo-Metal-Work

Representative image for illustrative purposes, the item supplied will correspond to the specifications indicated.

ISO compact cylinder version
  • Female stem
  • Male stem

No queries yet, leave the first!
Privacy
Shipments
Returns


Compact pneumatic cylinder with a diameter of 25 mm and a stroke of 60 mm, double-acting and prepared for magnetic detection. The pneumatic cylinder is manufactured according to ISO 21287, with an aluminium body and a rod with a female or male thread, in stainless steel, and polyurethane seals.

The cylinder body is made of extruded aluminium, and the heads have been removed to facilitate installation, improve robustness and precision. polyurethane seals. It has a wide range of anchors and fixings, which provide numerous fixing points. Magnetic detectors can be mounted inserted in the slots of the cylinder body.



Technical characteristics of the pneumatic cylinder:

  • Manufacturer: Metal Work
  • Manufacturer reference: 2X00250060XP
  • Diameter and stroke: Ø25x60 mm
  • Type: Double acting pneumatic cylinder
  • Fluid Type: Air with or without lubrication
  • Manufacturing standard: ISO 21287
  • Maximum working pressure: 10 bar (1 Mpa)
  • Minimum operating pressure: 1 bar (0.1 Mpa)
  • Type of gasket: Polyurethane
  • Operating temperature: -10ºC to +60ºC
  • Construction Type: Stainless Steel Stem
  • Air connection thread size: M5
  • Stem diameter: 10mm
  • Stem thread: M8

Dimensions of compact cylinders ISO Metal work adajusa

The cylinder is prepared for the mounting of magnetic detectors and different accessories. The supply only includes the cylinder, the rest of the accessories must be ordered separately.


Other races and executions can be supplied upon request.




Professional use material, install in compliance with the regulations in force at the installation site.

For further information you can download the technical sheet by clicking on the "Attached Files" tab.
